| Input Voltage | VAC | 100–240 (±10%) |
| Operating Current (Max) | A | ≤0.3 |
| Electrostatic Output Range | kV | 0–80 |
| Gun Body Diameter | mm | Ø42 |
| Nozzle Diameter (Standard) | mm | Ø12 |
| Gun Length | mm | 270 |
| Weight (without cable) | g | 850 |
| Powder Hopper Content | g | 500 (Integrated) |
| Max. Powder Flow Rate | g/min | 400 |
| Coating Thickness (Single Pass) | μm | 50–180 |
| Transfer Efficiency | % | ≥75 |
| Safety Standards | - | CE, UL, RoHS 3.0 |
Optimized Features & Advantages of M20 Manual Powder Coating Gun:
Global Voltage Compatibility: Operates on AC 100-240V, 50/60Hz (Auto-Adapting).
Proven Technology: Incorporates 5 exclusive patents for superior performance.
Intuitive Touch Control: User-friendly touchscreen interface for fast, effortless operation.
Faraday Cage Effect Solution: Ensures uniform coverage on complex geometries (recesses, edges, corners).
Exceptional Finish Quality: Achieves high-build coatings (100μm - 200μm+) in a single pass, eliminating orange peel.
Factory Reset Protection: One-touch restore to default settings prevents operational errors.
Automatic Edge Wrapping: Enhanced Faraday penetration significantly reduces manual touch-up/rework.
Smart Electrostatic Control: Advanced system auto-adjusts powder output for diverse product requirements.
Robotic Integration Ready: Enables "Continuous Auto-Parameter Adjustment" for precision beyond manual capability.
